SQJ964EP
www.vishay.com
THERMAL RATINGS (T A = 25 °C, unless otherwise noted)
Vishay Siliconix
100
I DM Limited
10
Limited by R D S (on) *
100 μ s
1
0.1
0.01
T C = 25 °C
S ingle Pul s e
I D Limited
BVD SS Limited
1 m s
10 m s
100 m s , 1 s , 10 s , DC
0.01
0.1 1
10
100
V D S - Drain-to- S ource Voltage (V)
* V GS > minimum V GS at which R D S (on) i s s pecified
Safe Operating Area
2
1
Duty Cycle = 0.5
0.2
Note s :
t 1
t 2
0.1
0.01
0.1
0.05
0.02
S ingle Pul s e
P DM
t 1
t 2
1. Duty Cycle, D =
2. Per Unit Ba s e = R thJA = 85 °C/W
3. T JM - T A = P DM Z thJA (t)
4. S urface Mounted
10 -4
10 -3
10 -2
10 -1
1
10
100
600
Sq uare Wave Pul s e Duration ( s )
Normalized Thermal Transient Impedance, Junction-to-Ambient
S11-2419-Rev. B, 19-Dec-11
5
Document Number: 65167
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
